Refrigerator, Two Section Undercounter, Stainless Doors with Lock - UR48B01

HoshizakiHoshizaki brand logo

Refrigerator, Two Section Undercounter, Stainless Doors with Lock

Model: UR48B01

UR48B-01, Refrigerator, Two Section Undercounter, Stainless Doors with LockTitle UR48B01UR48B-01, Refrigerator, Two Section Undercounter, Stainless Doors with LockTitle UR48B01UR48B-01, Refrigerator, Two Section Undercounter, Stainless Doors with LockTitle UR48B01
UR48B-01, Refrigerator, Two Section Undercounter, Stainless Doors with LockTitle UR48B01
UR48B-01, Refrigerator, Two Section Undercounter, Stainless Doors with LockTitle UR48B01
UR48B-01, Refrigerator, Two Section Undercounter, Stainless Doors with LockTitle UR48B01

Color : Stainless Steel

product image
Stainless Steel

Key Features

  • Net capacity of 12 cubic feet

  • Innovative air distribution system distributes air evenly to maintain product temperature

  • Enamel coated evaporator coil for extended life

  • Stainless steel exterior (front, sides, top) and a stainless steel interior

  • Extruded aluminum flush mount door handle

  • (2) stainless steel doors with ABS interior liner

  • R290 refrigerant

  • Automatic off-cycle defrost

Read More

Description

The UR48B-01 Steelheart Series Undercounter two section refrigerator with stainless doors is a space saving workhorse. Engineered to maintain food safe temperatures in 100°F ambient conditions. With a net capacity of 12 cubic feet this efficient undercounter refrigerator and front air flow design is perfect for hot/tight kitchens. The UR48B-01 is constructed of stainless steel, which protects this unit from accidental damage and rust. Plus, it is easy to clean.
Read More

Available from Mark's Appliance, serving customers throughout Southern IL & St. Louis, MO.

Features
Specifications

Features

Net capacity of 12 cubic feet

Innovative air distribution system distributes air evenly to maintain product temperature

Enamel coated evaporator coil for extended life

Stainless steel exterior (front, sides, top) and a stainless steel interior

Extruded aluminum flush mount door handle

(2) stainless steel doors with ABS interior liner

R290 refrigerant

Automatic off-cycle defrost

Includes cylinder locks (-01) (factory installed)

Nominal Compres. of 798 BTU/hr at 1/5 HP

115v/60/1, 10 ft. cord and plug

ENERGY STAR® qualified

7-7-7 Warranty (seven years labor, seven years parts, seven years compressor)

Specifications

Dimensions & Weight

Width-
Height-
Length-
Weight249 lbs.
Width48 in.
Depth30 in.
Height33.75 in.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width-
Shipping Height-
Shipping Length-
Shipping Weight289 lbs.
Total of Shipping Weight289 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement-
Dimensional Weight-
Total of Cubes-
Total of Dimensional Weight-

Product Details

Electrical SpecsElectrical Connection: 5 – 15P NEMA, 115v/60/1, 10 ft. cord and plug, Energy Consumption: 1.05 kwh/day, Amperage: 3, Max Fuse/HACR Breaker: 15 A
Operating LimitsAmbient Temp Range: 45 – 100°F, Voltage Range: 104 – 126V, Control Setpoint Range: 32 – 52°F, Refrigerant: R290
Refrigeration DataNominal Compres. of 798 BTU/hr at 1/5 HP, Heat Rejection: 278 BTU/hr
Shipping Weight249
Storage SpecsNominal storage capacity: 13.66 ft3, Interior storage capacity: 12 ft3, Door opening: 19.5″ W x 23″ H, Depth with door fully extended: 52.5″ D, Shelves included: 2

Warranty

Parts7 Years
Labor7 Years
Compressor7 Years
