Crescent Cuber Icemaker, Remote-cooled, 3 Phase - KMS2000MLJ3
Color : Stainless Steel
Key Features
Dimensions: 30″ W x 24″ D x 32-7/8″ H
Up to 1910 lbs of ice produced per 24 hours
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, Beverage Dispensers
Mount 2 units side-by-side for 2x the ice production
Produces crescent shaped ice cubes
Protected by H-GUARD Plus Antimicrobial Agent
R-404A refrigerant (7.1 oz. / 201 g)
Description
Available from Mark's Appliance, serving customers throughout Southern IL & St. Louis, MO.
Features
Dimensions: 30″ W x 24″ D x 32-7/8″ H
Up to 1910 lbs of ice produced per 24 hours
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, Beverage Dispensers
Mount 2 units side-by-side for 2x the ice production
Produces crescent shaped ice cubes
Protected by H-GUARD Plus Antimicrobial Agent
R-404A refrigerant (7.1 oz. / 201 g)
Ambient temperature range: 45 – 100°F
Water temperature range: 45 – 90°F
Water pressure: 10 – 113psig
Voltage range: 187 – 253V
13 amps (20 Amp Max fuse)
Three phase, See Remote Condenser, *115V supply for the KMS Ice Maker is supplied from the 230V SRK Remote Condenser
Clean ice and easy maintenance lead to longer unit life span
Five Years: Parts & Labor warranty on evaporator.
7.1 kwh/100 lbs.@ 90/70
EverCheck™ alert system
CycleSaver™ design
Heat Rejection:31200 BTU/hr
Three Years: Parts & Labor warranty on entire machine.
Specifications
Product Details
| Shipping Weight | 206 lbs |
| Utility Consumption | 7.1 kWh per 100 lbs @ 90/70, 20 gal of Potable Water per 100 lbs @ 90/70 |
| Electrical Specs | Three phase, See Remote Condenser, *115V supply for the KMS Ice Maker is supplied from the 230V SRK Remote Condenser, Amperage: 13, Max Fuse/HACR Breaker: 20 A |
| Operating Limits | Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 187 – 253V, Heat Rejection: 31200 BTU/hr, Refrigerant Charge: R-404A, (7.1 oz. / 201 |
| Plumbing Specs | 1/2″ FPT Inlet, Minimum 3/8″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Hard Pipe or Equivalent |
Dimensions & Weight
| Width | 30 in. |
| Height | 32.88 in. |
| Length | 24 in. |
| Weight | 206 lbs. |
| Depth | 24 in. |
| Height | 32.875 in. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | 37.88 in. |
| Shipping Length | 29 in. |
| Shipping Weight | 246 lbs. |
| Total of Shipping Weight | 246 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 13.7 ft³ |
| Dimensional Weight | 170.29 lbs. |
| Total of Cubes | 13.7 ft³ |
| Total of Dimensional Weight | 170.29 lbs. |
Warranty
| Parts | 3 Years |
| Labor | 3 Years |
| Parts (Compressor) | 5 Years |
| Parts | 5 Years |
| Labor | 5 Years |
