Crescent® Cuber Icemaker, Water-cooled, 3 Phase - KMH2100SWJ3

HoshizakiHoshizaki brand logo

Crescent® Cuber Icemaker, Water-cooled, 3 Phase

Model: KMH2100SWJ3

KMH-2100SWJ3, Crescent Cuber Icemaker, Water-cooled, 3 PhaseTitle KMH2100SWJ3KMH-2100SWJ3, Crescent Cuber Icemaker, Water-cooled, 3 PhaseTitle KMH2100SWJ3
KMH-2100SWJ3, Crescent Cuber Icemaker, Water-cooled, 3 PhaseTitle KMH2100SWJ3
KMH-2100SWJ3, Crescent Cuber Icemaker, Water-cooled, 3 PhaseTitle KMH2100SWJ3

Color : Stainless Steel

product image
Stainless Steel

Key Features

  • Up to 2000 lbs of ice produced per 24 hours

  • Stack 2 units for 2x the ice production

  • Produces crescent shaped ice cubes

  • Durable stainless steel exterior

  • Compatible bins & dispensers, sold separately: Kloppenberg 2115

  • R-404A refrigerant (3 lbs. 1.4 oz. / 1400 g)

  • 10 amps (20 Amp Max fuse)

  • 2.92 kwh/100 lbs.@ 90/70

Read More

Description

The KMH-2100SWJ3 is capable of producing approximately 2000 lbs of crescent cubed ice, Stack 2 units for 2x the ice production in the same floor space! Our efficient double-sided KMEdge™ stainless steel evaporators create our unique crescent shaped ice cubes. It is the purest and hardest ice on the market and is a perfect fit for a wide range of applications. This Water-cooled, Stackable, High Capacity, 3 Phase icemaker features a CycleSaver™ design and includes the EverCheck™ alert system making the unit energy efficient and simple to maintain. The KMH-2100SWJ3 requires a Three phase, 208-230v/60/3, 4 wire, including ground electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: Kloppenberg 2115. Please consult the Specification Sheet for additional details.
Read More

Available from Mark's Appliance, serving customers throughout Southern IL & St. Louis, MO.

Features
Specifications

Features

Up to 2000 lbs of ice produced per 24 hours

Stack 2 units for 2x the ice production

Produces crescent shaped ice cubes

Durable stainless steel exterior

Compatible bins & dispensers, sold separately: Kloppenberg 2115

R-404A refrigerant (3 lbs. 1.4 oz. / 1400 g)

10 amps (20 Amp Max fuse)

2.92 kwh/100 lbs.@ 90/70

Three phase, 208-230v/60/3, 4 wire, including ground

Clean ice and easy maintenance lead to longer unit life span

EverCheck™ alert system

CycleSaver™ design

Heat Rejection: 22400 BTU/hr

Three Years: Parts & Labor warranty on entire machine

Five Years: Parts & Labor warranty on evaporator

Specifications

Product Details

Utility Consumption2.92 kWh per 100 lbs @ 90/70, 15 gal of Potable Water per 100 lbs @ 90/70
Electrical SpecsThree phase, 208-230v/60/3 4 wire, including ground, Amperage: 10, Max Fuse/HACR Breaker: 20 A
Operating LimitsAmbient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 187 – 253V, Heat Rejection: 22400 BTU/hr, Refrigerant Charge: R-404A, (3 lbs. 1.4 oz.
Plumbing Specs1/2″ FPT Inlet, Minimum 3/8″ Nominal ID Copper Water Tubing or Equivalent, 3/8″ FPT Outlet, Minimum 3/8″ Nominal ID Drain Hard Pipe or Equivalent, Minimum 3/8″ Nominal ID Drain Hard Pipe or E
Shipping Weight440

Dimensions & Weight

Width-
Height-
Length-
Weight440 lbs.
Width36 in.
Depth40 in.
Height36.438 in.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width-
Shipping Height-
Shipping Length-
Shipping Weight480 lbs.
Total of Shipping Weight480 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement-
Dimensional Weight-
Total of Cubes-
Total of Dimensional Weight-

Warranty

Parts3 Years
Labor3 Years
Parts (Compressor)5 Years
