Name: Crescent® Cuber Icemaker, Water-cooled
Brand: Hoshizaki
SKU: KM660MWJ
Availability: BackOrder

Crescent® Cuber Icemaker, Water-cooled

Model : #KM660MWJ

Crescent® Cuber Icemaker, Water-cooled

Model: KM660MWJ

Crescent® Cuber Icemaker, Water-cooled

Model: KM660MWJ

Color : Stainless Steel

Key Features

Up to 647 lbs of ice produced per 24 hours
Mount 2 units side-by-side for 2x the ice production
Produces crescent shaped ice cubes
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, DB-130H, DB-200H, DM-200B
R-404A refrigerant (15.2 oz. / 431 g)
12.35 amps (20 Amp Max fuse)
Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included

Description

The KM-660MWJ is capable of producing approximately 647 lbs of crescent cubed ice. Our efficient double-sided KMEdge™ stainless steel evaporators create our unique crescent shaped ice cubes. It is the purest and hardest ice on the market and is a perfect fit for a wide range of applications. This Water-cooled, Slim Line Modular icemaker features a CycleSaver™ design and includes the EverCheck™ alert system making the unit energy efficient and simple to maintain. The KM-660MWJ requires a Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included. Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, DB-130H, DB-200H, DM-200B. Please consult the Specification Sheet for additional details.

Documents

Specification Sheet

View | Download

PDF, 1.78 MB

Instruction Manual

View | Download

PDF, 4.87 MB

Parts Manual

View | Download

PDF, 3.58 MB

Warranty Statement

View | Download

PDF, 999.31 KB

Service Manual

View | Download

PDF, 5.81 MB

Available from Mark's Appliance, serving customers throughout Southern IL & St. Louis, MO.

Features

Specifications

Features

Up to 647 lbs of ice produced per 24 hours

Mount 2 units side-by-side for 2x the ice production

Produces crescent shaped ice cubes

Durable stainless steel exterior

Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, DB-130H, DB-200H, DM-200B

R-404A refrigerant (15.2 oz. / 431 g)

12.35 amps (20 Amp Max fuse)

Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included

Clean ice and easy maintenance lead to longer unit life span

4.28 kwh/100 lbs.@ 90/70

EverCheck™ alert system

CycleSaver™ design

Heat Rejection: 11100 BTU/hr

Three Years: Parts & Labor warranty on entire machine

Five Years: Parts & Labor warranty on evaporator

Specifications

Product Details

Utility Consumption	4.28 kWh per 100 lbs @ 90/70, 16.1 gal of Potable Water per 100 lbs @ 90/70
Electrical Specs	Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included., Amperage: 12.35, Max Fuse/HACR Breaker: 20 A
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 104 – 127V, Heat Rejection: 11100 BTU/hr, Refrigerant Charge: R-404A, (15.2 oz. / 431
Plumbing Specs	1/2″ FPT Inlet, Minimum 1/4″ Nominal ID Copper Water Tubing or Equivalent, 3/8″ FPT Outlet, Minimum 1/4″ Nominal ID Drain Hard Pipe or Equivalent, Minimum 1/4″ Nominal ID Drain Hard Pipe or E
Shipping Weight	180

Dimensions & Weight
