Name: Crescent® Cuber Icemaker, Remote-cooled
Brand: Hoshizaki
SKU: KM1301SRJZ
Availability: BackOrder

Crescent® Cuber Icemaker, Remote-cooled

Model : #KM1301SRJZ

Crescent® Cuber Icemaker, Remote-cooled

Model: KM1301SRJZ

Crescent® Cuber Icemaker, Remote-cooled

Model: KM1301SRJZ

Color : Stainless Steel

Key Features

Produces crescent shaped ice cubes
Up to 1400 lbs of ice produced per 24 hours
Stack 2 units for 2x the ice production
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-800, B-900, B-1150, B-1300, B-1500, B-1650
R-404A refrigerant (5 lbs. 15.2 oz. / 2700 g)
15.9 amps (20 Amp Max fuse)
4.28 kwh/100 lbs.@ 90/70

Description

The KM-1301SRJZ is capable of producing approximately 1400 lbs of crescent cubed ice, Stack 2 units for 2x the ice production in the same floor space! Our efficient KMEdge™ double-sided stainless steel evaporators create our unique crescent shaped ice cubes. It is the purest and hardest ice on the market and is a perfect fit for a wide range of applications. The KM-1301SRJZ icemaker features a CycleSaver™ design and includes the EverCheck™ alert system making the unit energy efficient and simple to maintain. The KM-1301SRJZ requires a Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included. If neutral is not available transformer kit (HS-5030) is required. Remote condenser sold separately. Compatible bins & dispensers, sold separately: B-800, B-900, B-1150, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details.

Documents

Specification Sheet

View | Download

PDF, 1.29 MB

Warranty Statement

View | Download

PDF, 999.31 KB

Available from Mark's Appliance, serving customers throughout Southern IL & St. Louis, MO.

Features

Specifications

Features

Produces crescent shaped ice cubes

Up to 1400 lbs of ice produced per 24 hours

Stack 2 units for 2x the ice production

Durable stainless steel exterior

Compatible bins & dispensers, sold separately: B-800, B-900, B-1150, B-1300, B-1500, B-1650

R-404A refrigerant (5 lbs. 15.2 oz. / 2700 g)

15.9 amps (20 Amp Max fuse)

4.28 kwh/100 lbs.@ 90/70

Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included. If neutral is not available transformer kit (HS-5030) is required

Clean ice and easy maintenance lead to longer unit life span

EverCheck™ alert system

CycleSaver™ design

Integrated ultrasonic bin control

Simple, one-hour cleaning and assisted cleaning process with CleanAssist

Heat Rejection: 18900 BTU/hr

Three Years: Parts & Labor warranty on entire machine

Five Years: Parts & Labor warranty on evaporator

Specifications

Product Details

Utility Consumption	4.28 kWh per 100 lbs @ 90/70, 14 gal of Potable Water per 100 lbs @ 90/70
Electrical Specs	Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included. If neutral is not available transformer kit (HS-5030) is required, Amperage: 15.9, Max
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 187 – 253V, Heat Rejection: 18900 BTU/hr, Refrigerant Charge: R-404A, (5 lbs. 15.2 oz
Plumbing Specs	1/2″ FPT Inlet, Minimum 3/8″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Hard Pipe or Equivalent
Shipping Weight	335

Dimensions & Weight
