Cubelet Icemaker, Remote-cooled - FD650MRJZC

HoshizakiHoshizaki brand logo

Cubelet Icemaker, Remote-cooled

Model: FD650MRJZC

FD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZCFD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZCFD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZCFD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZCFD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZC
FD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZC
FD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZC
FD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZC
FD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZC
FD-650MRJZ-C with URC-5FZ, Cubelet Icemaker, Remote-cooledTitle FD650MRJZC

Color : Stainless Steel

product image
Stainless Steel

Key Features

  • Up to 588 lbs of ice produced per 24 hours

  • Durable stainless steel exterior

  • Mount 2 units side-by-side for 2x the ice production

  • Produces small cubelet nugget-style ice

  • Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900

  • 2 second rinse every hour to remove sediment

  • R-404A refrigerant (2 lbs. 3.3 oz. oz. / 1001 g)

  • 10.9 amps (20 Amp Max fuse)

Read More

Description

The FD-650MRJZ-C is capable of producing approximately 588 lbs of cubelet (nugget-style) ice per day. Cubelet ice is the most popular ice for drinks – as it cools the beverage quickly and absorbs the flavor making an easy-to-chew treat. This Remote-cooled icemaker features an Advanced CleanCycle24™ design plus a greaseless bearing auger construction making it simple to maintain. The FD-650MRJZ-C requires a Single phase, 115v/60/1, 3 wire, including ground electrical connection. ENERGY STAR® qualified. Please consult the Specification Sheet for additional details.
Read More

Available from Mark's Appliance, serving customers throughout Southern IL & St. Louis, MO.

Features
Specifications

Features

Up to 588 lbs of ice produced per 24 hours

Durable stainless steel exterior

Mount 2 units side-by-side for 2x the ice production

Produces small cubelet nugget-style ice

Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900

2 second rinse every hour to remove sediment

R-404A refrigerant (2 lbs. 3.3 oz. oz. / 1001 g)

10.9 amps (20 Amp Max fuse)

4.95 kwh/100 lbs.@ 90/70

Single phase, 115v/60/1, 3 wire, including ground

Advanced CleanCycle24™ design

ENERGY STAR® qualified

Heat Rejection: 5900 BTU/hr

Three Years: Parts & Labor warranty on entire machine (Serial numbers VxxxxxJ and after)

Five Years: Parts warranty on Compressor, air-cooled condenser coil

Specifications

Product Details

Electrical SpecsSingle phase, 115v/60/1, 3 wire, including ground, Amperage: 10.9, Max Fuse/HACR Breaker: 20 A
Utility Consumption4.95 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Operating LimitsAmbient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 104 – 127V, Heat Rejection: 5900 BTU/hr, Refrigerant Charge: R-404A, (2 lbs. 3.3 oz.
Plumbing Specs1/2″ FPT Inlet, Minimum 1/4″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Hard Pipe or Equivalent
Shipping Weight205

Dimensions & Weight

Width-
Height-
Length-
Weight205 lbs.
Width22 in.
Depth24 in.
Height26 in.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width-
Shipping Height-
Shipping Length-
Shipping Weight245 lbs.
Total of Shipping Weight245 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement-
Dimensional Weight-
Total of Cubes-
Total of Dimensional Weight-

Warranty

Parts3 Years
Labor3 Years
